Material And Operation Conditions

Efficiency: H13 / H14

Media: Micro glass fiber

Frame: ≥260℃ Stainless steel

Sealant: Red silica gel(260℃), Ceramic glue(350℃)

Gasket: Silicon gel plate(260℃), Glass fiber rope(350℃)

Separator: 0.035mm aluminum foil

Optional thickness: 80 ~ 292mm

Max Temperature: 260℃/350℃

Max Humidity: 100% (Imported glass fiber)

Product feature

It can be used at stated high temperature for long time

Big media area and high efficiency

100% factory inspection

Large air flow and low resistance

Wedge shaped pleat design to prevent the filter media from damage

Specification

Application

Places with high requirement of cleanliness, such as aviation, electronic, semiconductor, chip, biological pharmaceutical, hospital, and food processing factory, etc.

Air conditioning and ventilation system(terminal filtration and hot wind type high temperature oven).

Types of Air Filters

Pre-Filters, Final Filters, Panel Filters

Cartridge Dust Collector, Baghouse Dust Collector, Mist Collector, Fume Collector Filters

HEPA Filters, Link Panel Filters, Pleated Filters, Gas Phase, Spray Booth, High Efficiency

Metal Mesh Filters, Baffle Filters, Grease Filters, Foam Filters

Electronic Filters, Electrostatic Precipitator Cells

Filter Housings, Filter Banks, Air Cleaners

Rated efficiency from 1 thru 20 (99.999% efficient @ 0.10 micron particle size)

Custom industrial air filters

Custom HVAC commercial air filters
